APLUSLIFT HW-10KBP-A 10000 LB 2-POST FLOOR PLATE HEAVY DUTY CAR LIFT WITH 3 YEAR WARRANTY

Description

🚗 The Ultimate Floor Plate 2-Post Lift for Auto Shops & Home Garages

The APlusLift HW-10KBP-A is a 10,000 LB 2-post floor plate car lift designed for mechanics, auto repair shops, and serious car enthusiasts who need a reliable, high-capacity lifting solution. Built with a strong double “S” column design, combo arm assembly (symmetrical & asymmetrical), and an advanced hydraulic system, this lift provides maximum stability, safety, and efficiency for a variety of vehicle repairs and maintenance tasks.

With a durable chain-drive lifting system, reinforced steel construction, and CE-certified safety features, the HW-10KBP-A ensures long-lasting performance and smooth operation—all at an affordable price.

🔧 Why Choose the APlusLift HW-10KBP-A?

✅ 10,000 LB Heavy-Duty Lifting Capacity – Handles cars, SUVs, and light trucks effortlessly.
✅ Floor Plate Design – Ideal for low-ceiling garages while maintaining maximum lift height.
✅ Combo (Symmetrical & Asymmetrical) Arm Assembly – Versatile lifting for various vehicle sizes.
✅ 6’9” Max Lifting Height with Truck Adapters – Provides excellent undercarriage access.
✅ Double-Point Safety Lock Release – Secure and easy lowering with dual safety locks.
✅ Dual Hydraulic Cylinders – Chain Drive System – Reliable and powerful lifting operation.
✅ Heavy-Duty 3/8” Diameter Cables & 5” Pulley – Reduces stress for longer cable life.
✅ Automatic Arm Lock Restraints – Keeps vehicles securely positioned during service.
✅ Ultra-High Molecular Self-Lubricating Nylon Slider – Ensures smooth carriage movement.
✅ CE Certified for Safety & Quality – Tested for 115% dynamic load & 150% static load capacity.
✅ Industry-Leading 3-Year Warranty – Comprehensive 36-month parts protection.

📊 Full Specifications

🔹 Performance & Lifting Capacity

• Lifting Capacity: 10,000 LB
• Maximum Lift Height (With Truck Adapters): 81”
• Maximum Lift Height (Without Truck Adapters): 75”
• Maximum Lift Height (Bottom of the Arm to Ground): 71”
• Minimum Pad Height: 4”
• Lift Time: 50 Seconds
• Locking Mechanism: Double-Point Safety Lock Release
• Driving Mode: Dual Hydraulic Cylinders – Chain Drive System

🔹 Build & Design

• Overall Height: 113 5/8”
• Overall Width: 134 5/16”
• Drive-Through Width: 100”
• Column-to-Column Width: 109”
• Column Cross Section: 11”L x 7”W
• Column Steel Thickness: 13/64”
• Carriage Steel Thickness: 15/64”
• Carriage Yoke Thickness: 9/16”
• Arm Steel Thickness: 15/64”
• Base Plate Steel Thickness: 5/8”
• Floor Plate Cross Section: 10 5/8”W x 1 7/8”H
• Finish: Durable Powder Coated (Rust & Corrosion Resistant)
• Arm Assembly: Combo (Symmetrical & Asymmetrical) Arm Assembly
• Front Arm Range: Straight Front 3-Stage (22 7/8” to 42 5/8” reach)
• Rear Arm Range: Straight Rear 2-Stage (33 5/8” to 52 7/8” reach)

🔹 Power & Electrical

• Motor: 220V Single Phase | 3HP | 10A (Recommend a 30A Breaker)
• Hydraulic Oil Requirement: 3-5 gallons AW32/AW46 (Not Included)

🔹 Safety & Features

• CE Certified for Quality & Safety – Meets strict safety regulations.
• Heavy-Duty 3/8” Diameter Cables – Longer life & increased stability.
• Automatic Arm Lock Restraints – Secures the vehicle in place for safe operation.
• Ultra-High Molecular Nylon Slider – Ensures smooth carriage movement.
• Relief Valve Built into Power Pump – Prevents overloading & system damage.
• Rubber Door Guards – Protects vehicles from accidental dings & damage.
• Up-Limit Switch – Prevents cylinders from overextending.
• Beveled Diamond Plate Steel Floor Plate (5/32” with Supporting Bracket) – Ensures durability and stability.

📦 Shipping & Installation

• Shipping Weight: 1,370 LB
• Shipping Dimensions: 113”L x 22”W x 40”H
• Concrete Requirement: 6″ thick at 3500 psi reinforced with fiberglass or steel (4″ thick for vehicles 9000LB and below)

Parts Included:
✔ 4 Adjustable Screw Pads
✔ 4 Pieces of 4” Tall Truck Adapters (Height Extensions)
✔ 10 Anchor Bolts
✔ 10 Shims
✔ 2 Tool Trays
✔ 2 Toe Guards

💪 Built for Professional-Grade Lifting – Perfect for Auto Shops & Enthusiasts!

The APlusLift HW-10KBP-A is designed for mechanics, car restoration experts, and auto repair shops that need a high-capacity, ultra-durable 2-post lift at an affordable price. Its floor plate design makes it ideal for garages with low ceilings, while the reinforced steel structure and advanced hydraulic system ensure years of reliable performance.

🔥 Limited Stock – Order Now & Upgrade Your Garage with a Professional-Grade Lift! 🔥
